Curent Rating:100mA
Voltang Rating:30VDC
Dielectric Witchstanding voltage:250VAC For1 Minute
Contact Resistance:100mΩ Max.(initial)
Insulation Resistance:100mΩ Min
Operating Force:150±100gf
Total Travel:1.6±0.4mm
Operatong Life:50,000 Cycles Min
Solder specifications:260ofor5 seconds
Function:Momentary or self-lock
Operating Temerature:-20℃~+70℃
